CARS


The first ESTfield
(Audi)
(click here for more info)

1.8 BMW powered
ESTfield
(click here for more info)

2.0 Alfa powered
ESTfield
(click here for more info)

ESTfield Racing
(Lada power)
(click here for more info)

The V8 ESTfield

(click here for more info)



TYPICAL SPECIFICATION
Drive Train: Engine: Audi 1800cc / 4 cyl BMW / Toyota 1600cc / Lada 1600cc/ Moskvits / etc.
  Transmission: Lada 4-speed / BMW 5-speed / Lada straight-cut racing / Toyota 5-speed.
Suspension,
brakes and steering:
Front: Unequal length A-arms, Lada forged uprights and steering arms with anti-roll bar. Coil-over dampers and disc brakes.
  Rear: Lada live axle located by twin trailing arms and diagonal link. Coil-over dampers and drum brakes.
  Steering: Rack and pinion. Ford or BMW
  Wheels: 98 mm PCD - Lada, Lancia, Fiat, Alfa Romeo
Chassis and body:   Triangulated steel space-frame, 25x25x2 mm square section tube. Riveted aluminium cladding. Fibreglass moulded cycle-type wings, nose cone and scuttle.
  Length: 3210 mm
  Width: 1580 mm
  Wheelbase: 2323 mm
  Height: 1060 mm
  Kerb weight: ~600 kg
  Track


Front:
Rear:

1330 mm
1320 mm
